When preparing subfloors for tile layouts, framing out drywall partitions, or trimming down wooden door thresholds, dealing with high spots and distorted timber joists slows down your momentum. The Pridemark Iron Jack Plane Tempered Steel 250 x 50 mm serves as an indispensable mechanical hand helper to true up your lumber. Its heavy, stress-annealed cast iron frame features a precision-machined flat sole that glides evenly over uneven wood grains without flexing or chattering.
The industrial design highlights an adjustable 50mm tempered carbon steel cutting iron that holds its keen edge beautifully even when working through stubborn knots or dense hardwoods. Equipped with a brass micro-adjustment wheel and a lateral tracking lever, you can tune the depth and angle of your shavings down to a fraction of a millimeter. Complete with ergonomic, contoured handle grips that maximize user leverage while dampens hand vibration, this traditional bench tool ensures your surface preparations remain perfectly flat, square, and structurally sound.
Features & Benefits
- Premium tempered steel iron holds a razor-sharp shaving edge across dense lumber and composite boards
- Heavy cast iron base block provides the optimal physical weight needed to slide smoothly through tough grains
- Precision brass adjustment gears give installers total structural control over blade depth and alignment cutting
- Smoothly machined flat sole ensures perfectly accurate tracking to flatten warped joists or proud subfloor seams
Specifications
| Specification | Details |
|---|---|
| Product Type | Manual Bench Jack Plane |
| Product Name | Pridemark Iron Jack Plane |
| Tool Length | 250mm (Approx. 10 Inches) |
| Blade Width | 50mm (Approx. 2 Inches) |
| Blade Material | High-Grade Tempered Carbon Steel |
| Body Construction | Precision-Ground Heavy Cast Iron |
| Adjustment System | Mechanical Depth Wheel & Lateral Alignment Lever |
| SKU | PIJP |
Where It’s Used
Shaving down proud timber floor joists before screwing down backing boards, truing up wooden stud frame tracks, trimming tight interior doors, leveling old plywood subfloors, and general workshop carpentry.
Shaving down proud timber floor joists before screwing down backing boards, truing up wooden stud frame tracks, trimming tight interior doors, leveling old plywood subfloors, and general workshop carpentry.
Fitting
To secure an absolute trade-quality cut with your Pridemark Iron Jack Plane Tempered Steel 250 x 50 mm, check that the tempered steel iron is locked firmly inside the frog assembly. Turn the brass adjustment wheel to extend the blade tip just slightly below the cast iron sole plate, sighting down the base to verify that the cutting edge sits perfectly parallel. Secure your target timber piece rigidly in a workbench vise or clamp setup. Push the plane forward across the wood surface using smooth, continuous strokes, applying downward weight on the front knob at the start of your run and transitioning pressure to the rear tote handle as you clear the edge to prevent rounding off your materials.
To secure an absolute trade-quality cut with your Pridemark Iron Jack Plane Tempered Steel 250 x 50 mm, check that the tempered steel iron is locked firmly inside the frog assembly. Turn the brass adjustment wheel to extend the blade tip just slightly below the cast iron sole plate, sighting down the base to verify that the cutting edge sits perfectly parallel. Secure your target timber piece rigidly in a workbench vise or clamp setup. Push the plane forward across the wood surface using smooth, continuous strokes, applying downward weight on the front knob at the start of your run and transitioning pressure to the rear tote handle as you clear the edge to prevent rounding off your materials.
Reviews
There are no reviews yet.
